Flow Rate:160 107 67 44 L/min

Pressure:2.5 4 6.5 10 Mpa

Power Type:Available option driven by diesel engine,electric motor,hydraulic motor

>> Application

It is applied to geological and engineering prospecting such as the railway, the water conservancy, the met-allurgy, the build and the geology etc industry whose hole deep is within 1000m. Also it can be used to deliver water to high mountains or in the execution domain of middle and low pressure grouting and non excavating matching. This pump ha advantages such as small cubage, light mass, long life, simple operation and reliable per-formance, etc

Flow Rate:160 107 67 44 L/min

Pressure:2.5 4 6.5 10 Mpa

Power Type:Available option driven by diesel engine,electric motor,hydraulic motor

>> Application

It is applied to geological and engineering prospecting such as the railway, the water conservancy, the met-allurgy, the build and the geology etc industry whose hole deep is within 1000m. Also it can be used to deliver water to high mountains or in the execution domain of middle and low pressure grouting and non excavating matching. This pump ha advantages such as small cubage, light mass, long life, simple operation and reliable per-formance, etc

Flow Rate: 250 L/min

Pressure:2.5 Mpa

Power Type:Available option driven by diesel engine,electric motor,hydraulic motor

>> Application

BW-250 Mud Pumps is equipped with drilling rigs to drill holes with mud. During drilling mud pump pumps slurry to the hole to provide coat to the wall, to lubricate the drilling tools and to carry the rock debris up to the ground. It is applied to geological core drilling and prospecting drilling with depth less than 1500 meter.

Flow Rate:320 230 180 165 118 L/min

Pressure:4 5 6 8 9 Mpa

Power Type:Available option driven by diesel engine,electric motor,hydraulic motor

>> Application

BW320 mud pump are mainly used for irrigation agricultural machinery.the main characteristic is the high pressure, lift much, less energy consumption, easy operation, high quality and durable, easy to move, especially for mountain terraces of irrigation.

BW320 type mud pump is a horizontal triplex single acting reciprocating piston pump, which has two bore and fourth gear speed. Displacement and hole depth can be adjusted according to the application, the deepest can be adjusted to the application, the deepest can be used with 1800meters drilling rig, it also can be used cement perfusion.

Flow Rate:850 600 L/min

Pressure:2 3 Mpa

Power Type:Available option driven by diesel engine,electric motor,hydraulic motor

>> Application

BW850-2 Mud Pumps is equipped with drilling rigs to drill holes with mud. During drilling mud pump pumps slurry to the hole to provide coat to the wall, to lubricate the drilling tools and to carry the rock debris up to the ground.

BW850-2 mud pump are mainly used for irrigation agricultural machinery.the main characteristic is the high pressure,lift much,less energy consumption,easy operation,high quality and durable,easy to move,especially for mountain terraces of irrigation.

Flow Rate:850 600 350 L/min

Pressure:5 6 8 Mpa

Power Type:Available option driven by diesel engine,electric motor,hydraulic motor

>> Application

BW850-5 mud pumps horizontal, two-cylinder, double-acting, drive with built-in gear reducer and are designed to discharge washing liquid (water, mud) in the hole in exploration and stratigraphic drilling for oil and gas. Mud pumps are also widely used in the food, chemical and construction industries for pumping various non-aggressive liquids.
