BW160-10 Mud Pump with Good Price

Flow Rate:160 107 67 44 L/min

Pressure:2.5 4 6.5 10 Mpa

Power Type:Available option driven by diesel engine,electric motor,hydraulic motor

>> Application

It is applied to geological and engineering prospecting such as the railway, the water conservancy, the met-allurgy, the build and the geology etc industry whose hole deep is within 1000m. Also it can be used to deliver water to high mountains or in the execution domain of middle and low pressure grouting and non excavating matching. This pump ha advantages such as small cubage, light mass, long life, simple operation and reliable per-formance, etc

Inquire Now Chat Now

PRODUCT DESCRIPTION

>> Characteristics

>> Projects: Construction drilling of the projects e.g. prospection, geotechnical investigation(geological exploring), railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction;

>> Exploration: Coal mining exploration, Ore exploration;

>> Water well: Small hole diameter water well drilling;

>> Pipe-installing: Geothermal pipe-installing for heat pump;

>> Foundation piling: Small-diameter hole foundation piling drilling.

>> Specification

Model number	BW-160/10
Type	horizontal, triplex. single acting reciprocation piston pump
Stroke(mm)	70
Dia. of piston(mm)	70
Pump speed(min)	200	132	83	55
Output volume(1/min)	160	107	67	44
Pressure(Mpa)	2.5	4	6.5	10
Volumetric efficiency(%)	95
Overall efficiency(%)	75
Input hose diameter(mm)	51
Output hose diameter(mm)	25
Power of dynamic force(Kw)	11		13.24
Rotate speed of dynamics force(r/min)	1460		2200
Overall size(lengthwidthheight)	1450745970
Mass(kg)	380
