Cross Type Bit Tapered Connection Cross Bit In Quarring Rock Mining Small Hole Drilling Tungsten Carbide

Model: Cross Drill Bits

Degree: 4,6,7,11,12

Diameter:22-55mm

>> Application

The cross rock bit can be used under any rock drilling condition, it's hardly impacted by the model of drill rig and the rock performance

Inquire Now Chat Now

PRODUCT DESCRIPTION

Generally, chisel bit is mainly useed for hard rock, cross bit and button bit are mainly used for fissural rock. It is mainly used for diging into mine laneway and blasting holes in all drilling works matched with the taper drill rod. For different rock, we choose the different alloy to extend the working life of the drill bits.

>> Characteristics

Our taper drilling tools include taper drill bits and taper drill rod, and taper drill bits come into two types, taper button drill bits, and taper chisel drill bits. These drill tools are mainly equipped on rock drilling equipment, well drilling equipment and oil field equipment. They are widely used for rock drilling, blasting holes and other drill works in quarries, coal mines, rod and dam constructions and other similar projects.

>> Specification

Product Name:	Tungsten carbides tapered drill bit
Types	Rock cross drill bit, Tapered cross bits, Tapered button bits/ 34mm button drill bit
Application::	Use in granite and marble quarry, gold mine, railway, tunnel, etc. for drilling
Feature:	Tapered drill bits connect tapered drill steel of rock drill for drilling holes
Material:	High quality carbide and high quality steel
MOQ:	1pcs
We can design and manufacture according to your requirement of diameter, number air holes and carbide button shape.
Types of drill bits	Diameter (mm)	Taper Angle (Degree)	Length (mm)
Tapered chisel bits	20/22/28/30/32/34/36/38/40	4 degree/ 6 degree/ 7 degree/ 11 degree/ 12 degree	50/55/60/71/80
Tapered cross bits	24/26/28/30/32/33/34/35/36/3/38/40/42/48/50/55		50/55/60/71/80
Tapered button bits	28/29/30/32/33/34/35/36/37/38/40/41/42/45		50/55/60/71/80
